Roads & Bridges

Railways Authority, in order to rehabilitate the strategically placed railway bridge. EHAF’s responsibility was the thorough examination of the 300+ meter bridge composed of one movable and two...

The Egyptian National Railways appointed EHAF for the examination and assessment of the existing Nubareya Bridge. The bridge is a fixed, unidirectional way for trains consisting of 5...

Embaba Bridge was originally constructed in 1924 as a combined “Railway and Road” bridge. The Embaba Bridge was meant to efficiently service trains, automobiles and pedestrians. During its...

The project is to construct a bridge to connect the East and the West part of the ring road to be wholly connected.

Almost equal spans Cable Stayed Foot bridge consists of two equal spans (2x25m). Cables with different lengths are used to support the main girders.

The project consists of: Tunnel at the kilo 26+240 Bridge with total length 120 m at the intersection of the Regional Road with Belbeis Desert Road

The project is providing pedestrian passage in Shams Abu Dhabi Central Park area. In this project EHAF provides 8 pedestrian bridges with aesthetic appearance.

The project is steel pedestrian bridge over the main lagoon in Shams Abu Dhabi at Al Reem Island. The bridge is exhibit light structural solution,

The project is a steel pedestrian bridge over the main lagoon in Shams Abu Dhabi at Al Reem Island. The bridge is an exhibit light structural solution

Project Description El-Ananeia Bridge 400 m long twin bridges consisting of three sections. The middle section is a Bowstring arch steel bridge with a span of 40 m...

A 60 m steel foot bridge located at El-Moneeb station. The foot bridge consists of a simple span of 26m and steel stair cases in two opposite directions. The 10 cm,...

A 400 m long twin bridges consisting of three sections. The middle section is a Bowstring arch steel bridge with a span of 40 m provided with inclined crossing two layers...

The International Coastal Road crosses the Canal at sector 3b (Km 0.800). The Ministry of Housing and New Urban Communities planned to construct a steel bridge across the Canal

Bridge components are one of the most critical structural components as it is composed of Stay cables. The cable tension plays an important role in construction control and long term monitoring...

The project is two ways road with 2 new bridges, the road will be upgraded to connect with the new ring road. EHAF's scope  is to provide the consultancy services

The project is an unsymmetrical cable stayed steel pedestrian bridge over the main road between Residential areas and Offices area.

The project consists of two pedestrian bridges over the local roads between Residential areas. These bridges provide passage for people between residential area, and provide passage for fire engine in case...

The project is a cable stayed steel pedestrian bridge over the main road between Residential areas and Shopping Mall. It is exhibit light structural solution,

•The 30m Cable Stayed Foot bridge consists of two equal spans (2x15m). Cables with different lengths are used to support the main girder•Main elements of bridge are welded...
